The TB50 is a new generation of multimedia player created by NovaStar for full-color LED displays. This multimedia player integrates playback and sending capabilities, allowing users to publish content and control LED displays with a computer, mobile phone, or tablet. Working with our superior cloud-based publishing and monitoring platforms, the TB50 enables users to manage LED displays from an Internet-connected device anywhere, anytime.
Support for multi-screen synchronous playback and synchronous and asynchronous modes makes this multimedia player a perfect fit for a wide range of applications.
Thanks to its reliability, ease of use, and intelligent control, the TB50 becomes a winning choice for commercial LED displays and smart city applications such as fixed displays, lamp-post displays, chain store displays, advertisement players, mirror displays, retail store displays, door head displays, shelf displays, and much more.

Features

Output

• Loading capacity up to 1,300,000 pixels
• Maximum width: 4096 pixels
• Maximum height: 4096 pixels
• 2x Gigabit Ethernet ports
• These two ports serve as primary by default.
• Users can also set one as primary and the otheras backup.
• 1x Stereo audio connector
• The audio sample rate of the internal source is fixed at 48 kHz. The audio sample rate of the external source supports 32 kHz, 44.1 kHz, or* 48 kHz. If NovaStar's multifunction card is used for audiooutput, audio with a sample rate of 48 kHz is required.
• 1x HDMI 1.4 connector
• Maximum output: 1080p@60Hz, support for HDMI loop

Input

• 1x HDMI 1.4 connector In synchronous mode, video sources input from this connector can be scaled to fit the entire screen automatically.
• 2x sensor connectors Connect to brightness sensors or temperature and humidity sensors.


Control

• 1x USB 3.0 (Type A) port Allows for playback of content imported from a USB drive and firmware upgrade over USB.
• 1x USB (Type B) port Reserved
• 1x Gigabit Ethernet port Connects to a LAN, public network, or computer for content publishing and screen control.


Performance

• Powerful processing capacity
• - Quad-core ARM A55 processor @1.8 GHz
• - Support for H.264/H.265 4K@60Hz video decoding
• - 1 GB of onboard RAM
• - 16 GB of internal storage
• Flawless playback
• 2x 4K, 6x 1080p, 10x 720p, or 20x 360p video playback

Function

• All-roud control plans
• - Enables users to publish content and control screens from a computer, mobile phone, or tablet.
• - Allows users to publish content and control screens from anywhere, anytime.
• - Allows users to monitor screens from anywhere, anytime.
• Switching between Wi-Fi AP and Wi-Fi STA
• - In Wi-Fi AP mode, the user terminal connects to the built-in Wi-Fi hotspot of the TB50. The default SSID is “AP+Last 8 digits of SN” and the default password is “12345678”.
• - In Wi-Fi STA mode, the user terminal and the TB50 are connected to the Wi-Fi hotspot of a router.
• Synchronous and asynchronous modes
• - In asynchronous mode, the internal video source works.
• - In synchronous mode, the video source input from the HDMI connector works.
• Synchronous playback across multiple screens
• - NTP time synchronization
• - GPS time synchronization (The specified 4G module must be installed.)
• Support for 4G modules
• The TB50 ships without a 4G module. Users have to purchase 4G modules separately if needed.
• Network connection priority: Wired network > WiFi network > 4G network
• When multiple types of networks are available, the TB50 will choose a signal automatically according to the priority.

Storage Capacity RAM 1 GB
Internal storage 16 GB
Storage Environment
- Temperature -40°C to +80°C
- Humidity 0% RH to 80% RH, non-condensing
Operating Environment
- Temperature -20ºC to +60ºC
- Humidity 0% RH to 80% RH, non-condensing
Packaging dimensions (L×W×H) 385.0 mm × 280.0 mm × 75.0 mm
Packaging content: 1x TB50, 1x Wi-Fi omnidirectional antenna, 1x AC power cord, 1x Quick Start Guide
Dimensions (L×W×H) 274.3 mm × 139.0 mm × 40.0 mm
Net Weight 1234.0 g
