Battery spotlight with 7x10W RGB+WW Outdoor rated
The Smart ParNeo is an IP-rated, battery-powered spotlight that combines the key advantages of the iconic Smart BatPlus uplighter with a more flexible design, expanding the range of possible applications.
Equipped with 7 × 10W RGB+WW LEDs and powered by SpektraOS for advanced color control and consistency, this fixture supports both battery operation with CRMX wireless control and wired operation through power supply and chassis-mount connectors, ensuring seamless integration without limitations in either wireless or wired setups.
Smart ParNeo is compact and highly portable, featuring a round body with a flat base that makes it naturally suited for uplighting. It can also be easily converted into a focusable spotlight thanks to a quick-lock, self-standing sliding yoke, allowing use either as a ground-standing fixture or in suspended installations with cam-lock clamps.Additionally, the unit can be customized with a range of quick-mount colored covers, ideal for adapting the fixture to different event environments. A selection of light modifiers and accessories further enhances its functionality and versatility. The unit features built-in NFC for quick configuration and can be supplied with a fast-charging flight case for six units, making it perfectly suited for touring applications.
The Smart ParNeo is the latest flexible and multipurpose addition to the iconic SmartBat series, setting a new benchmark in portable professional lighting.
Main features:
- IP-rated battery spotlight with wireless CRMX and wired operations.
- 7×10W RGB+WW LEDs with SpektraOS for precise color control.
- Convertible design for uplighting or focusable spotlight use
- Customizable with covers and accessories for versatile applications
Technical specifications
LIGHT SOURCE
- Source: 7x10W RGB + Warm White LED
- Luminous flux: 2'927 lm @Full
- Lux: 1'493lx @5 m full
- CRI: Up to 90
- R9: Up to 80
- TLCI: Up to 80
- TM30 Rf: > 90
- TM30 Rg: < 107
- Source life expectancy: > 50.000 h
OPTICS
- Beam angle: 11°
- Field angle: 21°
- Additional optics: (optional) 20° and 40° - see available accessories
- Other: barn doors, snoot, additional filters - see available accessories
COLOUR SYSTEM
- Spektra OS: unmatched color precision and consistency
- Colour mixing: RGB + Warm White
- CCT: CCT control range from 2.800K to 10.000K, + / - green correction, tungsten emulation
- White presets: 2.700 K -10.000K
- Colour wheel: virtual colour wheel with macros
- Macros: several pre-built macros with adjustable speed
DYNAMIC EFFECTS
- Control Resolution: 16-bit dimmer and color control
- Static mode: selection of static colour
- Manual mode: manual adjustment of colour
- Auto mode: built-in programs with execution speed adjustment
CONTROL
- Supported Protocols: DMX512, RDM, CRMX, NFC
- DMX channels: 4/6/10/3 ch in legacy mode | 1/5/11/17ch
- RDM: for remote addressing and parameter configuration
- Display: Graphic User Interface
- IR: infrared sensor controlled by remote
- Master/Slave: for synchronised operation of more units linked in a chain
MOVEMENT
- Tilt: (up to) 20° with adjustable foot support
- ELECTRONICS
- Dimmer: linear 0 - 100% electronic dimmer
- Dimmer curves: 4 selectable dimming modes available
- Strobe / shutter: 1 - 25 Hz, electronic
- Selectable PWM: 1000 to 25000 Hz (selectable steps)
- Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (not included)
BATTERY
- Battery: 16,8V lithium
- Estimated battery life: up to 3 / 6 / 8 / 12 / 18 / 24 h (selectable)
- Recharge connection: magnetic fast-charge in case
- Recharge time: 4h (max)
- Battery level indicator: shown on display
CONNECTIONS
- Power connection: Seetronic powerCON TRUE IP65 IN/OUT
- Signal connection: Seetronic XLR 5p IN/OUT connectors
- Wireless Connection: integrated LumenRadio TiMo FX RDM - CRMX and W-DMX compatible
- Data connection: CRMX transreceiver
ELECTRICAL
- Mains power supply: 100-240V - 50/60Hz (SBPLUSNEOPOWER charger not included)
- Max power consumption (230V): 85W
- Standby power: 5,8 W
PHYSICAL
- IP rating: IP65 for temporary outdoor use
- Cooling: fan-free with natural convection
- Housing: Sturdy die-cast aluminium body
- Finish: black
- Operating temperature: Ta 0 to +45 °C (+32 to +113 °F)
- Dimensions (WxHxD): 194x249x147mm / 7.64''x9.8''x5.79''
- Weight: 4kg / 8.82lbs
INSTALLATION
- Suspension and fixing: hanging bracket for floor positioning with "Quick-Lock" system
- Bracket system: fast removible bracket
