Smart BatIP is the new waterproof version of the highly popular Smart Bat, expanding the possible application of this versatile luminaire to outdoor venues or for architectural applications. Smart BatIP is equipped with a lithium battery pack and a built-in Wi-Fi module for cable-free operation.
The transmission of the DMX signal is through Wi-Fi, the transmission unit WIFIBOX is compatible with any DMX controller or through the mobile app SmartColors available for any Android or IOS device.
Features:
4x8 W RGBW / FC LEDs
IP54 for temporary outdoor use
W-DMX: built-in Wi-Fi receiver
Adjustable foot support for tilt regulation (up to 20°)
Ergonomic carrying handle for transportation and positioning
SmartColors app for iOS and Android
Battery life: 12 hours (colour change mode)
LIGHT SOURCE
Source: 4x8W RGBW LEDs
Lux: 980lx @3 m full
Source life expectancy: > 50.000 h
OPTICS
Beam angle: 15°
Field angle: 30°
Lens diameter: 42mm
Additional optics: 25° and 45° optional
COLOUR SYSTEM
Colour mixing: RGBW / FC
White presets: 3200 K ~ 10.000K
Colour wheel: virtual colour wheel with presets
DYNAMIC EFFECTS
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment
BODY
Tilt angle: ° adjustable foot support for tilt regulation (up to 20°)
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
CONTROL
Protocols: DMX512
DMX channels: 4 / 6 / 10channel
W-DMX: integrated, proprietary protocol compatible with WIFIBOX, WDBOX
Display: LED display user interface
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
IR: infrared sensor controlled by remote
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 1 - 25 Hz, electronic
Operating temperature: 0° ~ +35°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
BATTERY
Battery: 11,1V lithium
Estimated battery life in colour change mode up to: 12h
Estimated battery life in full-mode up to: 6h
Re-charge connection: power cable
Re-charge time: 5h/max
Battery status: shown on display
PHYSICAL
Cooling: passive cooling and fan-free
Sospension and fixing: M12 threaded insert for easy clamp installation
Power connection: IEC 10 A IN
IP rating: 54
Dimensions (WxHxD): 138x191x145mm
Weight: 3,6kg
