SOMMER Octopus-G Fiberkabel, OM2 24 x 50/125 µm OM2, PE, sort SOMMER Octopus-G Fiberkabel, OM2 24 x 50/125 µm OM2, PE, sort SOMMER Octopus-G Fiberkabel, OM2 24 x 50/125 µm OM2, PE, sort

SOMMER Octopus-G Fiberkabel, OM2

24 x 50/125 µm OM2, PE, sort

Varenr: 141439
Alt. varenr: 590-0411-24
66,-eks. mva
Logg inn for å se dine nettopriser.
Ikke kunde? Søk om å bli kunde her.
Bestillingsvare, bestilles ved ordre. Ta kontakt for leveringstid.

WARP 1...

or to be more precise, you will be able to reach the simple speed of light with our SC-Octopus-G LWL cable. With it you can transmit your digital audio and video signals across large distances of up to 2 km (at 100 MBit/s). The multimode gradient fibres with a core diameter of 50 µm (insulation/cladding gauge 125 µm) is available for bandwidth: OM2 = 500 MHz,

The SC-OCTOPUS-G is perfect for underground laying


Advantages:

  • Digital signal transmission over long distances
  • Compact, lightweight, robust and metal free
  • Die-electrical glass fibre armouring (rodent protection)
  • Longitudinal water-tight in compliance with IED 60794-1-F5 (PE and FRNC/LSZH version)

Application:

  • High-quality, fast connection for the transmission of digital signals
  • Powerful data network installation in complex buildings (e.g. from office buildings to airport facilities)
  • Indoor and outdoor transmissions with long transmission lengths


Specifications:

Article number590-0411-24
NameSC-Octopus-G
EAN4049371005609
PropertiesIn-ground / burial
Application areaInstallation
Application areaStudio / Broadcast
Application areaMobile outdoor / indoor
ApplicationOptical fiber
Colourblack
Colour detailedblack
Construction(A-DQ(ZN)B2YMM)
Jacket materialPE
Jacket Ø mm7,60
Weight per 1 m g60
UV-resistantyes
Style variantround
Core (fiber) µm50
Cladding (fiber) µm125
Fibres24
QualityOM2
Temperature min. °C-15
Temperature max. °C70
Max. tensile force kN1,6
Width mm7,6
Height mm7,6
BPVo-EuroclassFca
