Where brute force reigns in a useful manner...
Advantages:
- Small in diameter
- Very durable due to the use of special coating mixtures
- Affordable price
Application:
- PA sound systems of all kinds
- For fixed installation
- For ELA technology
- Cabling of HiFi systems
Specifications:
| Article number | 415-0056FG |
|---|
| Name | Meridian Install SP215 |
|---|
| EAN | 4049371005258 |
|---|
| Properties | Halogen-free / LSZH |
|---|
| Properties | Analog |
|---|
| Properties | OFC oxygen free copper |
|---|
| Properties | FRNC flame retardant |
|---|
| Application area | Installation |
|---|
| Application area | Studio / Broadcast |
|---|
| Application area | ELA 100 V |
|---|
| Application | Installation cable |
|---|
| Application | Speaker Cable |
|---|
| Colour | grey |
|---|
| Colour detailed | dark grey |
|---|
| Construction | (2LIY1,50mm²)(ST)CY |
|---|
| Construction (audio) | (2LIY1,50mm²)Y |
|---|
| Jacket material | FRNC, shielded |
|---|
| Jacket Ø mm | 8,00 |
|---|
| Number of Channels (audio) | 1 |
|---|
| Inner conductor (audio) | 2 |
|---|
| Inner conductor (audio) mm² | 1,50 |
|---|
| Inner conductor Ø (audio) mm | 1,38 |
|---|
| AWG (audio) | 16 |
|---|
| Copper strands (audio) | 84 |
|---|
| Copper strand Ø (audio) mm | 0,15 |
|---|
| Conductor insulation Ø mm | 2,62 |
|---|
| Weight per 1 m g | 78 |
|---|
| Fire load per m kWh | 0,29 |
|---|
| Style variant | round |
|---|
| Packing | 500 m spool |
|---|
| Packing | 100 m spool |
|---|
| Temperature min. °C | -30 |
|---|
| Temperature max. °C | 70 |
|---|
| Width mm | 8 |
|---|
| Height mm | 8 |
|---|
| Capac. cond./cond. per 1 m (audio) pF | 150 |
|---|
| Capacity wire/wire at 1 ft. (audio) pF | 45,72 |
|---|
| Insulation resist. per 1 km GO | 0,005 |
|---|
| Insulation resist. per 1000 feet GO | 0,0015 |
|---|
| Insulation resist. per 1 km (audio) GO | 0,005 |
|---|
| Insulation resist. per 1000 feet (audio) GO | 0,0015 |
|---|
| Conductor resistance per 1 km O | 13 |
|---|
| Conductor resistance per 1000 ft. O | 3,9624 |
|---|
| BPVo-Euroclass | Fca |
|---|
