The RdmNode is a 4-port eDMX node designed to seamlessly convert Art-Net and sACN into DMX-512 and vice versa. Its compact DIN Rail form factor makes it an excellent choice for system integration and architectural lighting projects. This versatile device offers an intuitive drag-and-drop web interface, simplifying the configuration of data routing, merging processes, and port settings. With just a click, you can access presets for the most common data conversions, saving valuable time and effort.
When paired with the Visual Productions CueCore3 control system, the RdmNode unlocks 4 additional universes of control, making it an essential component to your lighting toolkit.
As a cutting-edge component of your DMX infrastructure, the RdmNode is prepared to handle bi-directional fixture data using the RDM over Art-Net protocol. A pending firmware upgrade will activate this functionality, ensuring your system stays ahead of the curve.
- Ethernet port
- Programming via web-interface
- 4 x DMX512-A (ANSI E1.11) port (Opto-isolated, bi-directional)
- RDM over Art-Net (pending firmware upgrade)
- Art-Net
- sACN
- Power consumption 9-24V DC 500mA
- Power over Ethernet (class I)
- Dimensions 105 x 86 x 60 mm (4.1 x 3.4 x 2.4 inches)
- Operating temperature -20°C to +50°C (-4°F to 122°F)
- Operating relative humidity 10% to 80% non-condensing
- Compliance: CE, ROHS, UKCA
