Each channel input is provided with individual microphone, music, master volume control, each line and paging console input with gain control, microphone input with gain, bass and treble tone control
Each channel output is provided with individual gain, bass and treble tone control, a gain control is also provided for each channel’s remote wall control
8 zone voice alarm contact closure to activate built-in tone voice alarm
Alert, evacuation and alarm; three styles of pre-recorded chimes are provided with tone control
EMC and ground for external voice alarm generator input
Connected via standard RJ45 terminated CAT 5 cable
4 swift keys for direct all channel BGM and paging access
5 levels of priority from highest to lowest are: MIC 1, fire alarm, remote paging console, remote control panel and background music
AC 110V or 240V input with voltage switch and DC 24V operation
Monitor output with independent volume control
Outputs: 0.775V / 600?
Frequency response (MIC): 80Hz-18KHz (+1/-3dB)
Frequency response (Line): 20Hz-20KHz (+1/-3dB)
Power supply: 110V/60Hz & 240V/50Hz DC 24V
Power consumption: 20W
Dimensions (H x W x D): 132 x 484 x 304mm
Weight: 10.3kg
