eLPA2-350
Stereo amplifier delivering 350W, bringing classic Ecler reliability to a lightweight, versatile and affordable format. Features an internal crossover filter.
Main features
- 2 analogue audio inputs x 2 powered audio outputs
- Ultra light technology
- Built-in crossover filter
- Efficient progressive ventilation system
- Rotary input attenuation controls on front panel
- POWER ON, SIGNAL, CLIP, PROTECT LED indicators
- Efficient short-circuit, overheat and DC signal protection
- Permanently activated anti-clip circuit
- Balanced XLR3 inputs
- Amplified outputs with terminal and Speakon connectors
Technical specifications
- Output channels: 2
- Output connection: Speakon & binding posts
- Output configuration: 2x345 W RMS @4 ohm
- Input channels: 2
- Input connection: XLR3 balanced, RCA & 6.35mm Jack
- Max output @4 ohm: 280W
- @8 ohm bridge: 560W
- Input impedance: 20k ohm (10k ohm unbalanced)
- Frequency response: 10Hz-58kHz
- THD+Noise: <0.05%
- SNR: >85dB
- CMRR: >55dB
- AC mains: 230V@47-63Hz
- Power 1/3 @4 ohm: 581.0W
- Power 1/8: 376.5W
- Idle: 40.0W
- Cooling: Progressive ventilation, rear-to-front airflow
- Protections: DC/Short-circuit/Clip/Thermal Yes
- Filters: 150Hz/18dB oct (CH1=low, CH2=high)
- Output settings: STEREO/PARALLEL/BRIDGE
- Gain: 26dB/32dB adjustable
- Installation: 19" rack (2RU)
- Dimensions: 482.6x88x266mm
- Weight: 5.5kg
- Shipping weight: 6.9kg
