Lo-Z/Hi-Z switchable Class-D amplifier (Lo-Z: 120W x2 @4?, 100W x2ch @3?/8?, Hi-Z: 120W x2ch or 200W x1ch, 70V/100V) equipped with 1 stereo/2 mono line inputs; can be combined with the MA2120 mixer amplifier.
Easy setup, and a user-friendly interface for effortless operation
Supporting Lo-Z (120W x2ch @4? or 100W x2ch @3?/8?) and Hi-Z (120W x2ch or 200W x1ch, 70V/100V) speaker systems
1 stereo/2 mono line inputs
Output EQ for optimizing the sound of each Output channel
Built-in speaker EQ optimum for Yamaha VXC/VXS series speakers, as well as HPF and selectable LPF settings
Capable of controlling sources and volumes seperately in two areas (Source/volume zoning)
Service areas or zoning areas can be expanded by adding a PA2120
Remote volume control and microphone on/off switching via optional DCP control panels (DCP4V4S, DCP1V4S, DCP4S, max 2 units)
Intelligent protection function ensures safe, reliable operation
Certified by ENERGY STAR
Certified as Yamaha Eco Products
Space-saving 1U rack size (*sufficient space must be provided above and below the unit for airflow and cooling.)
