LUMIPIX15IP is a tour-ready LED pixel batten conceived to be fully versatile and perform outdoor, delivering advanced brightness and colour mixing by offering individual pixel control of each cell. The robust die-cast aluminium structure with omega quick lock socket on the bracket and the waterproof power and signal connector make LUMIPIX15IP suitable for the most demanding environments.
Features:
LED batten with 15 individually controllable RGBW LED
Waterproof housing and connections for outdoor usage
Extensive colour palette with precise mixing and powerful output
LIGHT SOURCE
Source: 15x10W RGBW LEDs
Luminous flux: 3'587lm
Lux: 4'771lx @3 m full
Source life expectancy: > 30.000 h
OPTICS
Beam angle: 16°
Field angle: 30°
Additional optics: magnetic frost holder on board
COLOUR SYSTEM
Colour mixing: RGBW / FC
CTC: CTC control through dedicated DMX channel
White presets: 2.800 K - 10.000K
Colour wheel: virtual colour wheel with presets
Macros: several pre-build pixel macros with adjustable speed
DYNAMIC EFFECTS
Pixel patterns: pre-programmed dynamic and static patterns
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
BODY
Hardware on-board: OMEGA sockets for quick rigging (clamp included)
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
CONTROL
Protocols: DMX512
DMX channels: 4 / 6 / 10 / 60 / 65channel
Pixel control: pixel2pixel control
W-DMX: included, wireless solution receiver
Display: black OLED high resolution display
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 0 ~ 30 Hz, electronic
Battery backup: battery backup for user operation without connecting to the main power
Operating temperature: -10° ~ +45°
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 161W
Power consumption (at 120 V): 162W
Output (at 230 V): 23 units on a single power line
Output (at 120 V): 12 units on a single power line
PHYSICAL
Cooling: passive cooling and fan-free
Sospension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
Signal connection: Seetronic XLR 5p IN/OUT connectors
Data connection: W-DMX receiver
Power connection: Seetronic powerCON waterproof IN/OUT connectors
IP rating: 65 for temporary outdoor application, not for fixed installation
Dimensions (WxHxD): 992x206x160mm
Weight: 8,6kg
