NB! STRØMKABEL LEVERES UTEN STØPSEL, SE TILBEHØR FOR ALTERNATIVER
Pixie Beam is a fast, bright and compact moving LED beam luminaire. Some looks are all about scale. The Pixie Beam takes this idea to a different level featuring incredible speed and infinite rotation of both pan and tilt.
Features:
Single 60 W Osram Ostar RGBW LED with 100 mm lens delivers a bright, consistent 4,5° beam
Compact, lightweight and incredibly fast - the PIXIEBEAM moves with 'moving mirror' speed
Infinite pan and tilt rotation for additional effects
LIGHT SOURCE
Source: 60W RGBW Osram Ostar LEDs
Lux: 11'120lx @3 m full
Source life expectancy: > 50.000 h
OPTICS
Beam angle: 4,5°
Lens diameter: 100mm
COLOUR SYSTEM
Colour mixing: RGBW / FC
CTC: CTC control through dedicated DMX channel
White presets: 2.000 K ~ 8.000K
Colour wheel: virtual colour wheel with presets
BODY
Pan angle: ° with 360° continuous rotation
Tilt angle: ° with 360° continuous rotation
Pan/Tilt resolution: bit 8 / 16 bit
Feedback: automatic repositioning after accidental movement
Body: aluminium structure with hi-resistance polycarbonate cover
Body colour: black
CONTROL
Protocols: DMX512, RDM
DMX channels: 14 / 16 / 18channel
RDM: RDM ready for fixture remote monitor and settings
Display: black OLED high resolution display
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
Hibernation: power safe mode when lost DMX
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Strobe / shutter: 1 - 25 Hz, electronic
Operating temperature: -10° ~ +45°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 82W
Power consumption (at 120 V): 82W
Output (at 230 V): 15 units on a single power line
PHYSICAL
Cooling: forced air with low noise fan
Sospension and fixing: any position with quick-lock omega brackets
Signal connection: Amphenol XLR 5p IN/OUT connectors
Power connection: Neutrik powerCON IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 208x300x144mm
Weight: 4kg
