Prolyte Produktnummer: BGR70-L050
BGR70 A low volume truss with extreme load bearing capacity The BGR70 truss is designed to create large spans that can hold heavy loads. Compared to conventional 100’er truss systems, the BGR70 truss is 40% stronger and safes up to 35% transport volume. Rectangular profiles create a truss that can be used for spans up to 45 metres, still allowing a centre point load of 750 kg. Zero deflection due to pre-cambering Using the unique pre-camber options, you can create an absolute straight truss. Depending on the applied load, a combination of spacers ranging from 0mm to 4mm can create a pre-camber effect that will result in zero deflection, despite the applied loading. This is a great feature when using motion or led screens. Application scope Due to its low volume and height, combined with a high load bearing capacity, the BGR70 truss is extremely suitable as a mother grid, or to support a front façade for large sets, like on dance festivals. Due to its zero deflection, the BGR70 truss is ideal in applications with motion or LED screens.
